Remote control electric garage Door |
Panel Steel thickness | 0.326mm/0.35mm/0.4mm/0.5mm, Panel Steel PE Paint thickness is 25mm |
Panel Construction and thickness | Steel+PU foam+Steel, 30/40/50mm thickness |
Stuff Material | Polyurethanes PU |
Tracks style | Double track for low headroom or Single track for standard headroom |
Track thickness | 1.5mm/1.8mm/2.0mm |
Track cover(Optional part) | Injury of the finger caused by the movements of rollers in vertical tracks will be effectively prevented by the track cover. It will seal the space between the wall and the vertical tracks so the finger can not be inserted in. |
Hinges/roller brackets & Bearing brackets thickness | 2.0mm & 2.5mm |
Nylon Rollers | 6200Z bearing,good quality Nylon, avoid dust |
Top/bottom weather seals | stretches made of Plastic or Aluminum, Seals are made EPDM |
Spring break safety brackets(Optional Part) | If spring broke , the spring break safe device will stop the door's falling to protect the people, kids or other things who is passing the garage. |
Cable break safety system (Opitonal Part) | If cable break, the system will stuck on tracks then prevent the door from droping. |
Motor style | Chain or belt style |
Motor Voltage | 110V or 220V |
Motor Force | 600N/800N/1000N/1200N/1500N/1800N |
Motor lift height | 2.2m, 2.5m, 2.8m, 3.1m, 3.4m |
Motor sensor/Alarming/Wall Switch/Wireless keypad/Back battery | Available |
Size | Width up to 5000mm, Height up to 3000mm |
Running Speed | 25cm/s |
Color | Customized according to your requirement |
Application | Factories, enterprises, office buildings, villas and other types of garage doors |




FAQ Q: What is your main product? A: As China leading manufacturer of special doors,our product range includes fire door,hospital door,ward door,industry cleaning room door,
Sound Proof Door,
Explosion Proof Door,explosion relief door,etc. Q: What kind of Certification do you have? A: After professional testing by relevant institution , we have got certificates of UL, CE, NFPA,BS,ISO9001,etc Q: How can I know your price? A: Tell us your requirement of the specification and the quantity, then we will send quotation to you. Q: How can you guarantee your product quality? A: Not only for the product certificates worth your trust,but we adopt quality control by four testing procedures: Initial inspection, re-inspection, final inspection and sampling inspection to guarantee the quality. Q: What is your payment terms? A: Normally, 30% - 50% of total amount by T/T as deposit and balance should be paid before delivery. Irrevocable L/C at sight is also acceptable. Q: What is your delivery time? A: About 15 working days after deposit and drawing confirmed. FAQ Q: What is your main product? A: As China leading manufacturer of special doors,our product range includes fire door,hospital door,ward door,industry cleaning room door,sound proof door,
Explosion proof door,explosion relief door,etc. Q: What kind of Certification do you have? A: After professional testing by relevant institution , we have got certificates of UL, CE, NFPA,BS,ISO9001,etc Q: How can I know your price? A: Tell us your requirement of the specification and the quantity, then we will send quotation to you. Q: How can you guarantee your product quality? A: Not only for the product certificates worth your trust,but we adopt quality control by four testing procedures: Initial inspection, re-inspection, final inspection and sampling inspection to guarantee the quality.
Contact us if you need more details on Manual Roll Up Door. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Roll Up Garage Door、Garage Door. If these products fail to match your need, please contact us and we would like to provide relevant information.
Product Categories : Roller Shutters > Garage Rolling Door
